iSwitch 265HDMI 1.4 and HDCP 1.4 compliant, video resolution up to 1920×1200@60Hz 4:4:4
Support 4.95Gbps video bandwidth
Signal transmission distance can be extended up to 328ft / 100m via CATE/6/6A/7 cable
Support point-to-point signal extension
Support signal distribution, multicast mode, distributed matrix and video wall (up to 9 x 9) functions over a 1G Network Switch
Intelligent video wall class management makes it achievable of wall-in-wall or novel layouts of wall configurations
Support LPCM 2.0CH (32/44.1/48KHz) audio format
The encoder supports HDMI local loop output
Support audio embedding and extracting
Support USB/KVM function (one-to-one & one-to-many), and bidirectional
IR/RS-232 control (pass-through & Guest mode)
Support mainstream and sub-stream encoding modes
Stream parameters can be set via API commands
Controlled via panel buttons, IR, RS-232, TCP/IP, Web GUI and Controller
Support POE function (802.3af Class 3, PD mode)
Smart networking design for easy and flexible installation

Point-to-PointiSwitch AV over IP products are a direct replacement for AV Matrix (HDbaseT) solutions. Leverage IP infrastructure to route AV signals in offices, huddle rooms, conference rooms, or as content contribution (trunking) between locations. True plug-and-play, no need any IP settings.


One-to-ManyiSwitch efficiently deliver high-quality, low latency, AV to many displays on a floor, between floors, or across the entire organization.

Many-to-One SwitchingiSwitch lets you take content from multiple encoders and deliver it to one decoder connected to the same managed Ethernet switch.

Many-to-Many Video WalliSwitch include video wall processing that allows encoded AV content to be presented across an array of displays.

Many-to-Many Matrix SwitchingDigital signage systems are usually asymmetrical – a few sources feeding a large number of destinations.iSwitch simply integrates decoder and network drop for each display.

Support portrait layoutsIt supports 90°, 180°, 270° screen installation.
Preview SourceWith preview of all signal content
