Microphone cable with 2 conductors and shield. Black colour.
Main information
2 wires and shield.
100 m length cable.
Price per metre.
Black.
Type:
Microphone cable
Length:
100 m
Diameter:
6 mm
AWG:
24
Conductors:
2 x 0.22 mm2 + shield
Threads per conductor:
28 x 0.10 mm
Conductor insulation:
PE 1.40 mm
Shield:
80 coiled copper wires of 0.10 mm
Shield factor:
95%/ 95 %
Temperature range:
-20 ºC to 70 ºC
Conductor capacitance:
68 pF/m
Shield capacitance:
130 pF/m
Conductor resistance:
53 Ohm/Km
Shielding resistance:
25 Ohm/Km
Insulation resistance:
> 1 GOhm/Km
Characteristic impedance:
100 Ohm
Colour:
Black
