iShare X400 Pro
2x HDMI outputs enabling content sharing from the same source or different sources.
Support up to 4 sources shared on a single screen.
Support 1080P wireless sharing from Airplay, Miracast, Chromecast, or iShareX App.
Supports ultrasonic and Bluetooth near-field discovery technology.
Working with both 1080P and 4K wireless transmitter.
Provide 1x 4K HDMI input.
Provide 1x USB-B port for the host PC.
Support USB cam/mic/speaker transmission over WiFi.
Support 2x camera connection and switching.
Support USB devices switching between local USB-B and wireless laptops.
Support display content sharing to remote participant over video conference.
Provide 2x LAN ports for network isolating between staff and guest.
Support PoE with LAN port 1.
Support reverse control of sources from touch screen.
Provide native annotation and whiteboard tools with both outputs.
Analogue audio extraction on stereo unbalanced 3,5mm jack connector.
One channel RS232 can control 3rd party devices or be controlled.
Provide API commands for RS232 and Telnet control.
Provide powerful and intuitive web control interface.
Provide GPI control interfaces with customizable function.
All data transmitted is encrypted with RSA & AES.
Support with LAN EAP certification.
Support customization with home screen page.
Provide OTA (on-the-air) firmware upgrade.
Support digital signage streaming.
X400 Pro Telnet_Tcp_ API Commands
Datasheet
| Model |
iShare X400 Pro |
| Name |
Dual Screen BYOM Switcher |
| HDMI output |
1x HDMI 2.0, 1x HDMI 1.4 |
| Main output Resolution |
3840×2160@60Hz, 3840×2160@30Hz, 1920×1080@60Hz, 1280×720@60Hz, 1900×1200@60Hz, 1280×800@60Hz |
| Sub output Resolution |
1920×1080@60Hz, 1280×720@60Hz, 1900×1200@60Hz, 1280×800@60Hz |
| Format Compliance |
HDMI1.4/HDMI2.0 |
| Input video Capacity |
1080P @ =30Hz Airplay, Miracast, Chromecast
1080P @ =30Hz “iShareX” app
4K @ =30Hz for HDMI dongle
4K @ =30Hz for USB-C dongle
4K @30Hz for HDMI wired input |
| HDCP |
HDCP 1.4 |
| HDMI Input |
1x HDMI 19-pin female connector |
| Format Compliance |
HDMI1.4 |
| CEC |
Support |
| Analog audio Output |
Yes, 3.5mm jack |
| LAN port |
RJ45 x2 1000Mbps |
| USB interface |
USB-A 3.0 x3, USB-B 3.0x 1, Type-C(USB3.0) x1, USB 2.0 x3, Type-C(USB2.0) x1 |
| USB Camera over WiFi |
=1080P@30, MJPG |
| Audio Input |
AirPlay/Miracast/Chromecast, Windows/MAC Apps, buttons, USB Mic |
| Audio output |
jack, HDMI, jack + HDMI, USB Speaker |
| Control connectors |
3 pin Phoenix terminal/ RS232 interface |
| Number of windows simultaneously on screens |
= 5 |
| Number of simultaneous connections |
= 16(Max 2xAirplay or 2xMiracast or 2xChromecast, no limit with Apps and buttons) |
| Video Playback Frame Rate |
20-60 FPS |
| Latency |
80~120ms |
| WiFi Data rate |
Up to 1,200Mbps |
| Wireless transmission protocol |
WIFI IEEE 802.11 b/g/n/ac |
| Web security |
HTTPS |
| Frequency band |
2.4 GHz & 5 GHz |
| WIFI Antenna |
MIMO 2×2 and MIMO 1×1 |
| WIFI Encryption |
AES WPA PSK, WPA2 PSK |
| Control method |
Web GUI, Telnet, RS232 |
| DC Power input |
12V/3A |
| PoE |
YES, IEEE802.3at |
| Digital Signage |
YES |
| Dimension |
222mm x 120mmx 32mm (without antenna) |
| Net Weight |
850g |
| Storage Temperature |
-4° ~ +140° F (-20° ~ +60° C) |
| Humidity |
20%-90% (non-condensing) |
| Power Consumption |
30W (MAX) |
