ENTAR 10A is a two-way self-powered loudspeaker that incorporates a 700W amplifier, made of wood.
It consists of a 8" woofer with a 1,5." voice coil and a 1"compression turnable driver, and incorporates a signal processing DSP.
Thanks to this DSP, it is possible to select 4 equalization presets, 3 HPF filters with selectable frequency, tone control (treble and bass) and differentiated preset for use as a floor monitor or placed on a support.
It has an insertion vessel for a 35 mm support that allows 0º/10º angulations and rigging fixation points. Incorporates 1 Mic/Line input with level control.
Type
2-Way.
Class D amplifier
Power
Amplifier 700 W
LF Transducer
8" Woofer; 1,5." Voice Coil
HF Transducer
1" turnable compression driver
DSP
4 Presets,
3 HPF Filters, Bass / Treble Curve Adjustment
SPL Max
124 dB
Coverage Angle
(H x V) 85,2º x 53.5º
Frequency Range
70 Hz - 20 KHz
Connections
1 x Combi XLR3/Jack TRS 1/4" female,1 x XLR3 male
Enclosure material
Plywood and metal grille
Inserts / Rigging
Insertion: 35 mm - 0°/10° angulation;
Rigging: sections for rigging rail and fixing points
Power supply
AC 240 V / 50 - 60 Hz
Colour
Black
Dimensions
464.5 x 250 x 240 mm
Weight
11.5 Kg
