BOSE PAN &

A surface-mount pan-and-tilt bracket that enables adjustment for both pitch and yaw, suitable for mounting either horizontally or vertically. The bracket is designed to fit the 4 M8 threaded inserts on the rear panel of the following models: DesignMax DM3SE, DM5SE, DM6SE, and DM8SE; FreeSpace FS2SE and FS4SE; 402 Series V; AMM108; AMU105, AMU108, AMU206, and AMU208.

FEATURES

Applications

Designed for a wide range of applications, including:

• Indoor or outdoor use

SPECS

Technical Specification

• Colors

• Black, white

• Product Dimensions (H×W×D)

• 6.0 in x 4.4 in x 4.4 in (152 mm x 111 mm x 112mm)

• Net Weight

• 2.45 lbs (1.11 kg)

Product codes

• Pan and Tilt Black
• 889687-0100

• Pan and Tilt White
• 889687-0200

Included in Packaging

• (1) installation guide

• (1) Surface-Mount Pan and Tilt Bracket

• mounting screws & washers

DOWNLOADS

• Installation Guide

• Packaging Material Information

• CAD Files
