Key Features

• 1x DP 1.2
  • Backward compatible with DP 1.1
  • Each connector supports the maximum resolution of 4096×2160@60Hz or 8192×1080@60Hz.
  • Custom resolutions:
    • Max. width: 8192 pixels (8192×1146@60Hz)
    • Max. height: 4095 pixels (2188×4095@60Hz)
  • HDCP 2.2 compliant.
  • Supports accompanied audio.
  • Supports 144Hz input.
• Status LEDs:
  • On: The input source is accessed normally.
  • Off: No input source is accessed or the input source is abnormal.
• Specifications:
  • Weight: 550 g
  • Dimensions: 193 mm × 247.12 mm × 21.15 mm
  • Power consumption: 9.4 W
