Novastar VX600 Pro

Varenr: S07010512
Novastar VX600 Pro Novastar VX600 Pro
eks. mva

NovaStar VX600 Pro is an advanced all-in-one LED display controller designed for medium-to-high-end rental and stage control systems.

With support for 4K×2K@60Hz input resolution, up to 6 layers, and flexible video signal processing, it provides seamless control for ultra-wide and ultra-high LED screens. Equipped with 6 Ethernet ports and HDMI 2.0 input, the VX600 Pro ensures superior image quality and zero-frame latency when low-latency mode is enabled, making it ideal for real-time applications.

Key Features

Multiple Input Connectors:

  • 1x HDMI 2.0 (IN & LOOP)
  • 2x HDMI 1.3
  • 1x 3G-SDI (IN & LOOP)
  • 1x 10G optical fiber port (OPT 1)
  • 1x USB 3.0 (supports USB playback)

Output Connectors:

  • 6x Gigabit Ethernet ports (Max. 3.9 million pixels, width: 10,240 pixels, height: 8,192 pixels)
  • 2x Fiber outputs (OPT 1 & OPT 2 for copy or backup)
  • 1x HDMI 1.3 (monitoring display, 1920×1080@60Hz)
  • 1x 3D connector (supports third-party 3D emitter)

Audio Input and Output:

  • HDMI audio input
  • Independent 3.5 mm audio input/output
  • Adjustable output volume

Performance:

  • Maximum input resolution: 4096×2160@60Hz (HDMI 2.0)
  • Supports 8/10/12-bit video inputs and RGB 4:4:4/YCbCr 4:4:4/4:2:2 color formats
  • Zero-frame latency with low latency and ByPass mode enabled
  • Output synchronization using internal or external Genlock source
  • Pixel-level brightness and chroma calibration for enhanced image consistency

Flexible Screen Configuration:

  • Up to 6 layers with adjustable size, position, priority, and aspect ratio
  • Easy preset saving and loading (up to 256 presets)
  • Personalized image scaling: Full screen, Pixel-to-Pixel, Custom

Control Options:

  • Front panel knob, NovaLCT software, Unico web page, and VICP app

Additional Features:

  • USB playback (Plug-and-play with JPEG, PNG, BMP, MP4 formats)
  • End-to-end backup between devices, input sources, and Ethernet ports
  • Data saving after power failure
