LG IDB IR Touch 86" FHD 350cd 16/7

All Spec

PANEL

• Screen Size (Inch)

  86

• Panel Technology

  IPS

• Back Light Type

  Direct

• Aspect Ratio

  16:9

• Native Resolution

  3840 x 2160 (UHD)

• Refresh Rate

  60Hz

• Brightness

  390nit (Typ., without Glass)

• Contrast Ratio

  1,200:1

• Dynamic CR

  NO

• Color Gamut

  NTSC 68%

• Viewing Angle (H x V)

  178º x 178º

• Color Depth (Number of Colors)

  1.07 Billion colors

• Response Time

  8ms (G to G)

• Surface Treatment (Haze)

  Haze 28%

• Life time

  30,000Hrs (Min.)

• Operation Hours (Hours/Day)

  16/7

• Portait / Landscape

  NO / YES

CONNECTIVITY

• HDMI In

  YES (3ea)

• HDMI In (HDCP Ver.)

  2.2/1.4

• DP In

  NO

• DVI-D In

  NO

• RGB In

  YES

• Audio In

  YES

• RS232C In

  YES

• RJ45(LAN) In

  YES (1ea)

• IR In

  NO

• USB In

  USB3.0 Type A (3ea), USB2.0 Type A (3ea)

• HDMI Out

  NO

• DP Out

  NO

• Audio Out

  YES

• Touch USB

  USB2.0 Type B (2ea)

• External Speaker Out

  NO

• RS232C Out

  NO

• RJ45(LAN) Out

  NO

MECHANICAL SPECIFICATION

• Bezel Color

  Black

• Bezel Width

  T/R/L/B : 18.9/18.9/18.9/45.7mm

• Weight (Head)

  67.5Kg

• Packed Weight

  86.6Kg

• Monitor Dimensions (W x H x D)

  1957 x 1160 x 87mm

• Carton Dimensions (W x H x D)

  1863 x 1283 x 280mm

• Handle

  YES

• VESA Standard Mount Interface

  800 x 600 mm

FEATURE - HARDWARE

• Internal Memory (eMMC)

  32GB

• Wi-Fi/BT (Built-in)

  YES

• Temperature Sensor

  NO

• Auto Brightness Sensor

  NO

• Power Indicator

  YES

• Local Key Operation

  YES

FEATURE - SOFTWARE

• Booting Logo Image

  YES

• PIP

  NO

• PBP

  NO

• Screen Share

  YES

• Setting Data Cloning

  NO

• Crestron Connected

  NO

• Smart Energy Saving

  NO

• PM mode

  NO

• Wake on LAN

  NO

• Network Ready

  NO

• HDMI-CEC

  YES

ENVIRONMENT CONDITIONS

• Operation Temperature

  0 °C to 40 °C

• Operation Humidity

  10 % to 80 %

POWER

• Power Supply

  AC 100-240V~, 50/60Hz

• Power Type

  Built-in Power

POWER CONSUMPTION

• Typ.

  370W

• Max.

  500W

• BTU (British Thermal Unit)

  1262 BTU/Hr(Typ.), 1706 BTU/Hr(Max.)

• DPM

  0.5W

• Power off

  0.5W

SOUND

• Speaker (Built-in)

  YES (10W x 2)

CERTIFICATION

• Safety

  CB / NRTL

• EMC

  FCC Class "A" / CE

• ERP / Energy Star

  YES / NO

OPS COMPATIBILITY

• OPS Type compatible

  YES (Slot)

• OPS Power Built-in

  YES

SOFTWARE COMPATIBILITY

• Connected Care

  NO

LANGUAGE

• OSD

  English, Simplified Chineses, Catalan, Czech, Denmark, Arabic(Egypt), Finnish, French, German, Greek, Italian, Japanese, Korean, Netherlands(Dutch), Norwegian, Polski, Portugues(Europe), Portugues(Brazil), Romanian, Russian, Spanish, Swedish, Türkçe, Ukrainian, Traditional Chinese, Hungarian

ACCESSORY

• Basic

  Power Cord 3M*1, USB Cable (Type A-Type B) 5M*1, HDMI Cable 3M*1, Writing Pen*2pcs, User Manual, QSG, Carton Box, Remote Controller(include battery 2ea), Wifi module

• Optional

  NO

SPECIAL FEATURE

• Conformal Coating (Power Board)

  YES

DEDICATED FEATURE - TOUCH

• Available Object Size for Touch

  Ø3 mm ?

• Response Time ('Paint' app on Windows 10 PC)

  10ms ?

• Accuracy (Typ.)

  ±2.0mm

• Interface

  USB2.0

• Protection Glass Thickness

  4mm (Anti-Glare)

• Protection Glass Transmission

  0.87

• Operating System Support

  Windows 7/8/10/XP/Linux/Mac/Android (Windows XP/Linux/Mac Support one point touch)

• Multi Touch Point

  Max. 20 Points

DEDICATED FEATURE - CREATE BOARD

• CPU

  Dual core A73+Dual core A53

• GPU

  Dual Core Mail G51

• Memory(RAM)

  3GB

• Storage

  32GB

• Wi-Fi

  802.11a/b/g/n/ac

• LAN

  Gigabit LAN

• Bluetooth

  Bluetooth 4.0

• OS ver. (Android)

  Android 8
