InfoBit - iShare X400 Pro WL Dual Screen

Dual Screen BYOM Switcher

Varenr: iShare X400 Pro
InfoBit - iShare X400 Pro WL Dual Screen Dual Screen BYOM Switcher InfoBit - iShare X400 Pro WL Dual Screen Dual Screen BYOM Switcher InfoBit - iShare X400 Pro WL Dual Screen Dual Screen BYOM Switcher InfoBit - iShare X400 Pro WL Dual Screen Dual Screen BYOM Switcher
eks. mva
iShare X400 Pro

2x HDMI outputs enabling content sharing from the same source or different sources.

Support up to 4 sources shared on a single screen.

Support 1080P wireless sharing from Airplay, Miracast, Chromecast, or iShareX App.

Supports ultrasonic and Bluetooth near-field discovery technology.

Working with both 1080P and 4K wireless transmitter.

Provide 1x 4K HDMI input.

Provide 1x USB-B port for the host PC.

Support USB cam/mic/speaker transmission over WiFi.

Support 2x camera connection and switching.

Support USB devices switching between local USB-B and wireless laptops.

Support display content sharing to remote participant over video conference.

Provide 2x LAN ports for network isolating between staff and guest.

Support PoE with LAN port 1.

Support reverse control of sources from touch screen.

Provide native annotation and whiteboard tools with both outputs.

Analogue audio extraction on stereo unbalanced 3,5mm jack connector.

One channel RS232 can control 3rd party devices or be controlled.

Provide API commands for RS232 and Telnet control.

Provide powerful and intuitive web control interface.

Provide GPI control interfaces with customizable function.

All data transmitted is encrypted with RSA & AES.

Support with LAN EAP certification.

Support customization with home screen page.

Provide OTA (on-the-air) firmware upgrade.

Support digital signage streaming.




Datasheet
ModeliShare X400 Pro
NameDual Screen BYOM Switcher
HDMI output1x HDMI 2.0, 1x HDMI 1.4
Main output Resolution3840×2160@60Hz, 3840×2160@30Hz, 1920×1080@60Hz, 1280×720@60Hz, 1900×1200@60Hz, 1280×800@60Hz
Sub output Resolution1920×1080@60Hz, 1280×720@60Hz, 1900×1200@60Hz, 1280×800@60Hz
Format ComplianceHDMI1.4/HDMI2.0
Input video Capacity1080P @ =30Hz Airplay, Miracast, Chromecast
1080P @ =30Hz “iShareX” app
4K @ =30Hz for HDMI dongle
4K @ =30Hz for USB-C dongle
4K @30Hz for HDMI wired input
HDCPHDCP 1.4
HDMI Input1x HDMI 19-pin female connector
Format ComplianceHDMI1.4
CECSupport
Analog audio OutputYes, 3.5mm jack
LAN port RJ45 x2 1000Mbps
USB interfaceUSB-A 3.0 x3, USB-B 3.0x 1, Type-C(USB3.0) x1, USB 2.0 x3, Type-C(USB2.0) x1
USB Camera over WiFi =1080P@30, MJPG
Audio InputAirPlay/Miracast/Chromecast, Windows/MAC Apps, buttons, USB Mic
Audio outputjack, HDMI, jack + HDMI, USB Speaker
Control connectors3 pin Phoenix terminal/ RS232 interface
Number of windows simultaneously on screens= 5
Number of simultaneous connections = 16(Max 2xAirplay or 2xMiracast or 2xChromecast, no limit with Apps and buttons)
Video Playback Frame Rate20-60 FPS
Latency80~120ms
WiFi Data rateUp to 1,200Mbps
Wireless transmission protocol WIFI IEEE 802.11 b/g/n/ac
Web securityHTTPS
Frequency band2.4 GHz & 5 GHz
WIFI AntennaMIMO 2×2 and MIMO 1×1
WIFI Encryption AES WPA PSK, WPA2 PSK
Control method Web GUI, Telnet, RS232
DC Power input12V/3A
PoEYES, IEEE802.3at
Digital SignageYES
Dimension222mm x 120mmx 32mm (without antenna)
Net Weight850g
Storage Temperature-4° ~ +140° F (-20° ~ +60° C)
Humidity20%-90% (non-condensing)
Power Consumption30W (MAX)
