Cable spool for DMX interconnection. 2 conductors and braid shielding. Black colour. Impedance: 120 ohm.
Main information
- 2 wires + shield.
- 100 m length reel.
- Price per metre.
- Black.
| Type | DMX signal |
| Diameter | 6.5 mm |
| AWG | 22 |
| Conductors | 2 x 0.34 mm² |
| Threads per conductor | 7 x 0.25 mm |
| Conductor insulation | PE 1.70 mm |
| Shield | Copper coil shielding with 80 x 0.10 mm + AL / PT-foil + PE-filler |
| Shield factor | 100 % |
| Temperature range | -20 °C to 70 ºC |
| Conductor capacitance | < 65 pF/m |
| Shield capacitance | 115 pF/m |
| Conductor resistance | 53 Ohm/Km |
| Shielding resistance | 17 Ohm/Km |
| Insulation resistance | > 10 GOhm |
| Characteristic impedance | 120 Ohm |
| Colour | Black |
