iSpeaker DAP6

Built-in amplifier module, digital signal processing.

Support for POE power and Dante transmission, single channel, 60W@4 ohms.

The PoE module uses the Dante™ network protocol, 24-bit high quality audio (44.1K/48KHz) and control signals can be sent via Dante™ and controlled by the Dante™ Controller.

The module has an integrated DSP containing gain control, mute control, level, temperature display, 5-band equaliser, and limit control functions.

All functions are fully process-controllable from the Dante Controller on PC or Mac.

Datasheet

Model	iSpeaker DAP6
Name	Dante Active Speaker 6”
Technical	Bass 6.5-inch x1, treble 1-inch imported magnesium film + horn drive
Sensitivity	92dB (1w@1m)
Output power	15.4-30W
	(Determined by PoE output)
Maximum sound pressure	118dB
Power	60W
Impedance	8O
Vertical coverage	60°
Horizontal coverage	90°
Frequency Response Range	70 Hz-21kHz
Interface	RJ45
Transmission protocol	Dante
Power supply method	PoE power supply
DSP processing	support
Installation	Bring your own hangers
Net weight	4.1 Kg
Speaker size	197mm X 300mm X 118mm
