Veritas 2160BL

Bluetooth LZ 230V EU

Varenr: 892119-2110
Veritas 2160BL Bluetooth LZ 230V EU Veritas 2160BL Bluetooth LZ 230V EU
eks. mva

The award-winning Veritas series from Bose Professional delivers superior background/foreground music, paging and multimedia for commercial applications. Bluetooth® 5.0 wireless input and user-intuitive OLED screen with quick-start QR code simplify setup—whether you’re a pro installer or a DIYer. With four models to choose from, Veritas amplifiers offer the perfect combination of power, performance and flexibility.

For applications requiring more power in a low-impedance 4/8-ohm system, the 2160BL delivers robust sound for larger rooms, restaurants, and performance spaces. It provides high output with advanced DSP tuning, perfect for integrators needing a high-performance amplifier for dynamic commercial audio without the complexity of a 70V/100V system.

FEATURES

  • Premium amplification with advanced DSP for optimized performance

  • Bluetooth connectivity and RCA connectivity—no wire splicing required

  • Intuitive front-panel OLED screen for easy setup and control

  • Embedded quick-start QR code in the OLED screen simplifies installation

  • Supports low-impedance (4–8O) applications

  • Remote level control with Bose Professional or third-party wall controllers

  • Dynamic EQ adjusts bass levels to achieve a fuller sound even at low volumes

  • Up to 30 selectable EQ presets ensure Bose Professional signature sound performance and long-term reliability

  • Opti-Voice paging feature ensures clear speech intelligibility

Applications

Designed for a wide range of applications, including:

  • Retail stores
  • Restaurants and bars
  • Hospitality venues
  • Conference centers
  • Schools
  • Auxiliary zones

SPECS

Technical Specification

AMPLIFICATION

  • Channel Separation (Crosstalk)

  • = -58 dBu below rated power, 1 kHz

  • Dynamic Range

  • 88 dB

  • Frequency Response

  • 20 Hz – 20 kHz (+0/-3 dB) at 1 W, 1 kHz reference

  • Rated Power, Symmetrical

  • 2 × 160 W at 4 O / 2 × 80 W at 8 O

  • THD+N

  • = 0.5% at rated power

AUDIO INPUTS, ANALOG

  • Adjustment Range

  • -20 dB to +20 dB (line), 0 dB to +50 dB (page)

  • Input Channels

  • (2) balanced line, (2) unbalanced line, (1) balanced mic/line

  • Connectors

  • (2) RCA stereo pairs, (2) 5-pin Euroblock, (1) 4-pin Euroblock

  • Input Impedance

  • 20 kO (line), 2 kO (page)

  • Input Range

  • -8 dBu to +22 dBu (line), -58 dBu to +12 dBu (page)

  • Maximum Input Level

  • 22 dBu (line), 12 dBu (page)

  • Nominal Input Level

  • 4 dBu (line), -38 dBu (page)

  • Sensitivity

  • -8 dBu (line), -58 dBV (page)

AUDIO OUTPUTS, ANALOG

  • Channels

  • (2) loudspeaker, (1) unbalanced line

  • Connectors

  • (2) 2-pin inverted Euroblock, (1) RCA stereo pair

  • Nominal Output Level

  • 2 × 160 W at 4 O / 2 × 80 W at 8 O (loudspeaker), 2 dBu (auxiliary)

ELECTRICAL

  • Mains Connector

  • IEC C14 inlet

  • Mains Voltage

  • 100–240 VAC (±10%), 50/60 Hz

  • Protections

  • High temperature, output short circuit, excessively low/high AC line voltage

  • AC Power Consumption

  • 13.6 W standby, 500 W maximum

INDICATORS AND CONTROLS

  • Controls, Front Panel

  • Power on/off switch, input select switch (A/Bluetooth/B), rotary encoder

  • Controls, Rear Panel

  • Amplifier mode DIP switches, input gain knobs (A, B, page), page threshold knob, mute connector, ControlCenter ports

INTEGRATED DSP

  • A/D and D/A Converters

  • 48 kHz / 24-bit

  • Audio Latency

  • 10.4 ms (any input to speaker output or aux output)

  • Presets

  • Flat, 80 Hz high-pass filter, AMU105, AMU108, DesignMax (all models), EdgeMax (all models), FreeSpace FS (all models), subwoofer

  • Processing Functions

  • Loudspeaker EQ, Opti-Voice paging, Dynamic EQ

PHYSICAL

  • Cooling System

  • Fan system, left-to-right airflow

  • Product Dimensions (H×W×D)

  • 44 mm × 483 mm × 324 mm (1.7 in × 19.0 in × 12.8 in)

  • Net Weight

  • 4.4 kg (9.7 lb)

  • Shipping Weight

  • 5.8 kg (12.8 lb)

Product codes

  • 892119-1110
  • VERITAS 2160BL 120V US
  • 892119-2110
  • VERITAS 2160BL 230V EU
  • 892119-4110
  • VERITAS 2160BL 230V UK
  • 892119-3140
  • VERITAS 2160BL 100V JP
  • 892119-2140
  • VERITAS 2160BL 230V CN
  • 892119-5110
  • VERITAS 2160BL 240V AU

Included in Packaging

  • (4) mounting feet with pins

  • (2) 5-pin Euroblock connectors

  • (1) 4-pin Euroblock connector

  • (3) 2-pin Euroblock connectors

  • (1) power cord

  • (1) installation guide
