Digital mixing console,72 inputs, Dante

48 MIX, 12 Matrix, 2 Stereo. Dante144 ch

Varenr: DM7C
Digital mixing console,72 inputs, Dante 48 MIX, 12 Matrix, 2 Stereo. Dante144 ch Digital mixing console,72 inputs, Dante 48 MIX, 12 Matrix, 2 Stereo. Dante144 ch Digital mixing console,72 inputs, Dante 48 MIX, 12 Matrix, 2 Stereo. Dante144 ch
eks. mva

The DM7 Compact is a Dante-equipped versatile digital mixing console with unparalleled sound quality, ease of operation, and high reliability that make it perfect for a wide range of applications. The DM7 Compact is configured with 12 + 4 faders and a 1 x 12” + 1 x 7” multi-touch screen, and a rack-mountable with an optional RK1 rack mount kit.

  • Input mixing channels: 72 mono
  • Buses: 48 Mix + 12 Matrix + 2 Stereo
  • Display: 12.1" multi-touch screen x 1, 7" multitouch screen x 1
  • Faders: 16 (12 + 4)
  • Analog I/O: 16 inputs / 16 outputs
  • Dante: 144 in / 144 out
  • AES/EBU: 1 out
  • Slot: PY Slot x 1
  • USB Audio Interface: 18 in / 18 out
  • Power supply: Redundant power supply built-in
  • Power consumption: 240 W
  • Dimensions (W x H x D): 468 mm x 324 mm x 564 mm (18.5" x 12.8" x 22.2")
  • Net Weight: 16.5 kg (36.4 lb)
