InfoBit - iSwitch 265 Rx DEC

AVoIP RX DEC

Varenr: iSwitch 265R
InfoBit - iSwitch 265 Rx DEC AVoIP RX DEC InfoBit - iSwitch 265 Rx DEC AVoIP RX DEC
eks. mva
iSwitch 265
HDMI 1.4 and HDCP 1.4 compliant, video resolution up to 1920×1200@60Hz 4:4:4

Support 4.95Gbps video bandwidth

Signal transmission distance can be extended up to 328ft / 100m via CATE/6/6A/7 cable

Support point-to-point signal extension

Support signal distribution, multicast mode, distributed matrix and video wall (up to 9 x 9) functions over a 1G Network Switch

Intelligent video wall class management makes it achievable of wall-in-wall or novel layouts of wall configurations

Support LPCM 2.0CH (32/44.1/48KHz) audio format

The encoder supports HDMI local loop output

Support audio embedding and extracting

Support USB/KVM function (one-to-one & one-to-many), and bidirectional

IR/RS-232 control (pass-through & Guest mode)

Support mainstream and sub-stream encoding modes

Stream parameters can be set via API commands

Controlled via panel buttons, IR, RS-232, TCP/IP, Web GUI and Controller

Support POE function (802.3af Class 3, PD mode)

Smart networking design for easy and flexible installation



Point-to-Point
iSwitch AV over IP products are a direct replacement for AV Matrix (HDbaseT) solutions. Leverage IP infrastructure to route AV signals in offices, huddle rooms, conference rooms, or as content contribution (trunking) between locations. True plug-and-play, no need any IP settings.



One-to-Many
iSwitch efficiently deliver high-quality, low latency, AV to many displays on a floor, between floors, or across the entire organization.


Many-to-One Switching
iSwitch lets you take content from multiple encoders and deliver it to one decoder connected to the same managed Ethernet switch.


Many-to-Many Video Wall
iSwitch include video wall processing that allows encoded AV content to be presented across an array of displays.


Many-to-Many Matrix Switching
Digital signage systems are usually asymmetrical – a few sources feeding a large number of destinations.
iSwitch simply integrates decoder and network drop for each display.



Support portrait layouts
It supports 90°, 180°, 270° screen installation.

Preview Source
With preview of all signal content




Datasheet
HDMI Compliance HDMI 1.4
HDCP Compliance HDCP 1.4
Video Bandwidth 4.95Gbps
Video Compression Standard H.265/H.264
Transmission Distance 100m (CAT5E/6/6A/7)
IR Level 12Vp-p
IR Frequency Wideband 20 k – 60 KHZ
Video Resolution Up to 1920×1200@60Hz 4:4:4
Color Space RGB4:4:4, YCbCr 4:4:4,YCbCr 4:2:2
Color Depth Input: 8-bit, 10-bit, 12-bit (1080p@60Hz); Output: 8-bit
Audio Formats LPCM 2.0CH (32/44.1/48KHz)
Encoder 1x HDMI IN [Type A, 19-pin female]
1x HDMI OUT [Type A, 19-pin female]
1x AUDIO IN [3-pin phoenix connector]
1x AUDIO OUT [3-pin phoenix connector]
1x RS-232 [3-pin phoenix connector]
1x LAN [RJ45 connector, POE]
1x IR IN [3.5mm audio jack, 12V IR]
1x IR OUT [3.5mm audio jack, 12V IR]
1x USB Host [Type B, 4-pin female]
2x USB Devices [Type A, 4-pin female]
Decoder 1x HDMI OUT [Type A, 19-pin female]
1x LAN [RJ45 connector, POE]
1x AUDIO OUT [3-pin phoenix connector]
1x RS-232 [3-pin phoenix connector]
1x IR IN [3.5mm audio jack, 12V IR]
1x IR OUT [3.5mm audio jack, 12V IR]
2x USB Devices [Type A, 4-pin female]
Dimensions Encoder / Decoder: 204mm [W] x 95mm [D] x 21.5mm [H]
Weight Encoder: 472g, Decoder: 468g
Power Supply Input: AC100 – 240V 50/60Hz Output: DC 12V/1A
Power Consumption Encoder: 4.08W, Decoder: 2.76W
