InfoBit - programerbart knappe panel.

tcp/ip, 2x rs232, web gui, poe,

Varenr: iControl K06-EU
InfoBit - programerbart knappe panel. tcp/ip, 2x rs232, web gui, poe, InfoBit - programerbart knappe panel. tcp/ip, 2x rs232, web gui, poe,
eks. mva
iControl K06-EU

6 Keys Control Keypad, EU version

6x programmable backlit buttons with customizable label.

Each button’s color can be customized by the user.

1x volume control knob

2x RS-232, 2x IR and 2x Relay for control.

Support TCP/IP Control

Support IR learning function

Can be controlled and configured via user-friendly Web GUI

Can be powered by PoE

EU Wallplate version


Datasheet
Model iControl K06-EU
Name 6 Keys Control Keypad, EU version
Program Port TCP/IP
Output Port 2x RS232, 2x IR, 2x Relay
Output Connector 2x 3-Pin Pluggable terminal blocks, 2x 2-Pin Pluggable terminal blocks
Baud Rate 9600 baud, supports 9600, 19200, 38400, 57600, 115200
Power Consumption 2.5W (Max)
Operation Temperature 0 ~ +40?
Storage Temperature -10 ~ +55?
Relative Humidity 10% ~ 90%
Power Supply Input: 12VDC, PoE
Net Weight 215g
Case Dimensions 80mm x 80mm x 50.5mm, WHD
